The automatic cap sealing machine is precision built on sturdy welded steel Frame completely encloses in stainless steel.
The feed container moving on conveyor belt are feed into an infeed star wheel, Star wheel bring the container below the sealing head, during this bottle automatically Pick-up cap from delivery chute of cap feeding bowl, Sealing Head perform perfect Operation of threading and Sealing
technical specification
| Model No | DHL - 150 | |
|---|---|---|
| Output / Hours | 4200-4800(Output will be Depending on container / Cap size) | |
| Construction | Machine Cladding with SS 304 PVC Coated Sheet | |
| Electrical rating | Machine Main Motor 1HP | |
| Power Supply | 1 Phase / 230V | |
| Height of Conveyor | 860 mrn to 910 mm | |
| Overall Dimensions | 1830 mm (L) 900 mm (W) 1450 mm (H) | |
sailent features
- Stainless steel 304 construction
- GMP design
- The unit is made compact & versatile
- S.S. Elegantly Matt Finished Body
- Automatic cap feeder
- S.S. Slat conveyor
- Built in front control panel
