The semi automatic cap sealing machine is precision built on sturdy welded steel Frame completely encloses in stainless steel sheet.
Machine operator bring container along with cap below the rotating head. Sealing Head automatically comes down and does operation of threading and sealing.
technical specification
| Model No | DACS25 |
|---|---|
| Output | 2400 Containers (Depending on bottle size and operator skill) |
| Electrical Rating | 0.5 HP / 440 Volts / 3 phase / 50 Hz (Four Wire) For Main Machine |
| Container Size | 22 mm to 100 mm |
| Height of container | 50 mm to 210 mm Maximum, Option for other bottle Height available |
| Cap Size | 22 mm to 56 mm (With the help of required change parts). |
| Overall Dimensions | 575 (L) * 575 mm (W) * 1500 (H) Approx |
unique Features
- S.S. Elegantly Matt Finished Body
- Easy to operate
- Easy to maintain
- Built in front control panel
- The unit is made compact and versatile
*Note
We reserve the right to change specification without prior notice.
